The innovative slimline LMML2400 Series Mechanical Electro Magnetic Lock has been designed as an alternative to standard magnetic locks especially suited for situations where door height or narrow profile door frames create installation restrictions and appearance is of paramount importance.
The patented LMML incorporates both magnetic and mechanical design principles to achieve a superior holding force of up to 1000kg, whilst being 75% smaller than a standard 600kg Electro Magnet. The LMML2400 is capable of opening with up to 70kg side pressure on the door.
The LMML2400 Series also provides full monitoring with Lock Status Sensor (LSS), Door Status Sensor (DSS) and Early Warning (EW) security alarm indication. The device can be interfaced with building management and access control systems to control access and egress to hinged doors including fire rated models.
