FAQs

• 1.) Padlock must be unlocked. Pull the shackle to "open" position.
• 2.) Pull the rubber cover from the bottom of the Padlock out, and release the Torx screw.
• 3.) Release the Torx screw located below the shackle on the inside of the Padlock and remove the back cover.
• 4.) Release the 3 screws that secures the battery cover and pull the tab to remove the battery.
• 5. Replace the Rechargeable Lithium Battery, close the battery cover and secure it with the 3 screws.
• 6. Insert the back cover and tighten the Torx screw located below the shackle on the inside of the Padlock.
• 7. Tighten the Torx screw at the bottom of the Padlock and plug the rubber cover into place.
• 8. Push the shackle to ‘close’ position for the Padlock to automatically lock.

dormakaba are making the 30 lever obsolete & it's replacement is the 70 lever which is 10 mm longer.

It has been a requirement to specify the handing of certain variations of door furniture in the 6000 series range. This has predominantly applied to plates which have either a disabled turnsnib or indicator.

This has led to confusion in the past when ordering or specifying the required product, and also creating confusion when referring to handing of other door furniture in our brand.

To overcome this, we have created a new style of plate furniture which is now non handed. Where the need to have an indicator or turnsnib act in a certain direction, this can be easily done by removing the stop plate screw and plate and positioning it on the opposite side. This operation can be done on site by the installer.

U Spindle Kits - more options, more doors

Choosing the right spindle for Australian mortice locks just got easier.

The Salto U Spindle Kit comes with three pre-sized 7.6 mm split spindles (A, B, and 5) to suit door thicknesses from 35 to 48 mm, solving the common issue of mismatched spindle length.

It also includes an 8 mm solid spindle (3) compatible with ANSI and Euro mortice locks for doors 32 to 47 mm thick.

Just grab the size that matches and go.

The smart door lock is suitable for left hand and right hand opening door. As showed in figure, with the screwdriver, loosen the inside screw, rotate the handle 90 ° to left/right, then tighten the screw.

A. First select the suitable spindle according to the door thickness.

B. Install the spindle through spindle spring as showed in figure.

Note: Some existing triple lock kits top and bottom locks, including the plastic adaptor need to be reversed. This allows the triple kit to be locked from the inside by lifting the Ultra-Secua interior handle upwards.

Remote management.

Remote management is via a simple web-based system which can be accessed from any location on any device.

Once online, you can see at a glance which locks are free and ready to be allocated to new users.

The rental period can be set for an individual user, or group of users, and locks can even be set to unlock automatically.

The same system can manage multiple sites, simply and conveniently, all from one place.

How it works.

Using the Remote Allocation System (RAS) lock management software, new user codes are generated online. When the user enters it into their lock it immediately replaces the old code.

This ensures safe and secure access for new users without an administrator needing to be present.

1. On ordering the smart locks, a customer account is set up with a unique log-on to the RAS lock management website.
2. The smart locks are registered on the RAS website by the teams at L&F.
3. Use the website to generate a new code each time a new user wants access.
4. The current code works until the next code is entered.

The National Defense Authorization Act (NDAA) is the name for each of a series of United States federal laws specifying the annual budget and expenditures of the U.S. Department of Defense. In August 2018, US Congress passed the John McCain National Defense Authorization Act (NDAA), which contained a section called Section 889: Prohibition on Certain Telecommunications and Video Surveillance Services or Equipment.

To continue its strong growth and recognition in the world CCTV market, Milesight produce a range of NDAA Compliant cameras and NVR’s, which do not use or deploy critical components including SoCs (System on Chips) produced by NDAA banned component vendors. These are recommended for enterprises and critical applications where compliance is essential.

Lock Focus wooden fixing type W is suitable for timber panels with a round fixing hole.

It consists of a nut and pronged washer. The pronged washer bites into the timber when the nut is tightened. This prevents the lock from spinning in a round hole.

A large quantity of locking systems utilize the same depth and space measurements, although not all require the same amount of actual cuts on the key. InstaCode when printing a card always displays the maximum number of spaces to suit the largest number that could be required, therefore saving you from having to carrying multiple cards for the same space and depth information.

If you are cutting a key with only four cuts and the card has seven spaces just ignore the other positions that are not utilized with the key you are cutting.

The frequency of a remote control is critical to its working ability with a vehicle.

Vehicles such as the Holden Astra and Vectra range require a specific frequency range per vehicle.

The best way to test the frequency is by checking any existing keys with the AD35 remote frequency tester. Saying that, frequency band width alone is not a single sure way to determine if a remote can be programmed into a vehicle. The radio band is simply used to transmit data to and from the vehicle, which data is transmitted and the data composition is governed by other technologies. A perfect example is again the Holden Astra and Vectra which have identical frequencies and appearance, but can certainly not interchange.

The W4 can be used as a reader or controller. Wiegand 26-37 is supported, both input and output.

To set Wiegand format

9 26-37 # (factory default is Wiegand 26)
