Door thickness |
35-45mm |
Backset |
60mm |
max. Lever / knob projection distance may not include turnsnib |
69.5mm |
Strike |
70mm x 27mm x 1.2mm |
Latch |
60mm backset |
Latch face plate |
57mm x 25mm |
Door handing |
Non-handed knobs/levers |
Rose |
75mm |
Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.
