RISCO RisControl Alarm and Smart Home Controller with Z-Wave Gateway - RP432KPTZAUA

Product Code: RP432KPTZAUA

Are you a tradesperson?

Get access to our best prices



Description

The new RisControl controller is an 8-inch Touchscreen that incorporates Smart Home, Alarm, Surveillance (Cameras and NVR) and Z-Wave smart home devices in one user friendly interface, providing an exceptional user experience, ease of use, and a fully customizable interface.

In addition to acting as the Smart home gateway, the new RisControl can also act as a touchscreen keypad.

The RisControl user interface offers users complete control over the alarm, video, and Smart Home. Utilizing the straightforward wizard and powerful rule engine of RisControl, users can set up three types of automation: manual scenes, scheduled automation, and triggered automation, using a variety of smart home devices as well as detectors.

Features:

  • Home automation inside a touch screen – no additional gateway required.
  • Surveillance on same touch screen – Cameras and NVR.
  • Up to four (4) touch screens on one system – Master and 3 Slaves, each customizable to suit the location.
  • Event-driven security zone rules to control HA devices – no need for additional Z-Wave devices.
  • Can be installed in Standalone mode with or without surveillance (No security).
  • All settings, devices and rules are backed-up on the cloud.
  • Software updates are pushed to the RisControl to initiate the update when available and auto-install.
  • Grade 3 certified.

Technical Specifications:

  • CPU: A83T Octa-Core Cortex A7.
  • Ram: 1G DDR3L.
  • FLASH: 8G EMMC.
  • Display: 8 Inch IPS.
  • Resolution: 800x1280.
  • Illumination: 300 cd/m2.
  • Type Of Touch Capacitive touch, support 5-point touch.
  • Speaker: 8 Ohm / 1W.
  • Wi-Fi 802.11 b/g/n 2.4 GHz.
  • RisControl+ZWave for AU, 921.4MHz.
  • USB: Type C -Jack, Slave mode (USB 2.0).
  • System interface: RS-485.
  • Protection Wall Tamper.
  • Dimensions: 208 x 129 x 24 mm.
  • Weight: 481g.
  • Operating Voltage: 13V ±10%.
  • Current Consumption: 13V ±10%, 200 mA typical, 300mA max.
  • Operating Temperature -10°C to 55°C.
  • Standard: EN50131-3, Grade 3 Environmental Class II, PD 6662:2017.
Technical Specifications
Brand Risco
USB-C Interface Yes
Wi-Fi 2.4 GHz Connectivity Yes
Wi-Fi 5 GHz Connectivity No
Works with Z-Wave Yes
Diagonal Screen Size in inches 8
Screen Resolution 800 x 1280
Touch Screen Yes
RS-485 Interface Yes
